- Ambient temperature max. (°C)
- 100
- Ambient temperature min. (°C)
- -40
- Approvals
- ATEX II 1 D, ATEX II 1 G, ATEX II 2 D, ATEX II 2 G, ATEX II 3 D, ATEX II 3 G, PL c, SIL 2
- Connector type
- Removable cage clamp terminals
- Design
- Threaded barrel
- Electrical connection
- Terminal chamber
- Housing diameter (mm)
- ⌀ 18 mm
- Housing material
- Stainless steel
- Housing quality
- 1.4404 (AISI 316L)
- Length
- 71
- Mounting conditions
- Non-flush
- Operating voltage
- DC
- Output function
- NAMUR
- Protection class
- IP68, IP69K
- Quality active face
- LCP
- Rated switching distance (mm)
- 10
- Special features
- Pressure resistant, Wash down
- Switching frequency (kHz)
- 0.5
