Inductive Sensor

NI50-K90SR-Y1

Order ID no. 10074

Ambient temperature max. (°C): 70
Ambient temperature min. (°C): -25
Approvals: ATEX II 1 D, ATEX II 2 D, ATEX II 2 G, ATEX II 3 D, ATEX II 3 G, PL c, SIL 2
Design: Rectangular
Dimensions: 130 mm x 75 mm x 60 mm
Electrical connection: Terminal chamber
Height: 70
Housing material: Plastic
Housing quality: PBT-GF30-V0
Length: 140
Mounting conditions: Non-flush
Operating voltage: DC
Output function: NAMUR
Protection class: IP67
Quality active face: PBT-GF30-V0
Rated switching distance (mm): 50
Switching frequency (kHz): 0.1
Width: 100
