Inductive Sensor

BI20-G47-Y1

Order ID no. 10068

Ambient temperature max. (°C): 70
Ambient temperature min. (°C): -25
Approvals: ATEX II 1 D, ATEX II 2 D, ATEX II 2 G, ATEX II 3 D, ATEX II 3 G, PL c, SIL 2
Cable color: Blue
Cable length (m): 2
Design: Threaded barrel
Electrical connection: Cable
Height: 60
Housing diameter (mm): ⌀ 47 mm
Housing material: Metal
Housing quality: CuZn
Housing surface: Chrome-plated
Length: 150
Mounting conditions: Flush
Operating voltage: DC
Output function: NAMUR
Protection class: IP67
Quality active face: PA12-GF30
Rated switching distance (mm): 20
Switching frequency (kHz): 0.2
Width: 90
